About the Axis Q1786

Mounted a remarkable 200 feet away from the nest, the Axis Q1786-LE Network Camera is what we use for our Osprey Cam. Designed and manufactured in Sweden, it's widely considered the finest security and monitoring camera in the world.



It provides high-resolution footage – still or motion – in bright light, backlight, or no light at all. 



The camera has a 32x optical zoom with infrared lighting that can illuminate objects at up to 262 feet. It has a 4 MP (2592×1520) sensor with 4 million pixels that can can capture high resolution video at 60 fps.



It has a wide dynamic range for clarity, even when there are both dark and light areas in the scene, and low-light technology for high-quality color images even recorded in near darkness.

The camera can withstand temperatures between -40 °F to 140 °F and has electronic image stabilization and IK10-rated casing for impact resistance. It's IP66-, IP67-, and NEMA 4X-rated for protection against ice, water, corrosion and dust. And its defog functionality ensures clear images despite fog or smog.

The camera also comes with AXIS Motion Guard, AXIS Fence Guard and AXIS Loitering Guard pre-installed for proactive surveillance. It has extra capacity for other advanced analytics as well. 



It supports video with sound and features scene profiles, shock detection, corridor format with auto-rotation and barrel distortion correction for great image quality and cost-effective installation. You can even add additional functionality with its I/O ports.

Whether you have an Axis Q1786-LE camera trained on the local East End wildlife or you'd like a hi-res view of your property, this is the ultimate camera for the job.

Contact us for more information.

press to zoom

press to zoom

press to zoom

press to zoom
1/3

Technical Specifications

AXIS Q1786-LE

Download data sheet (PDF)

Camera

Image sensor    CMOS

Image sensor size    1/1.8

Lightfinder    Lightfinder

Wide dynamic range    Forensic WDR

Min illumination/ light sensitivity (Color)    0.18 lux

Min illumination/ light sensitivity (B/W)    0 lux



Video

Max video resolution    2560x1440

Max frames per second    50/60

Electronic image stabilization  √

Lens

Focal length    4.3 - 137 mm

Optical zoom    32

Horizontal field of view    60 - 2.3 °

Vertical field of view    39-1.3 °

Compression

Zipstream √

H.264    Baseline, High, Main

H.265    –

Motion JPEG √

Audio

Audio Support √

Network

PoE Class    3

Security

Signed firmware √

Secure boot    –

General

Remote focus    –

Remote zoom √

Built-in IR √

Local storage (memory card slot) √

Operating temperature    -40 to 60 °C

Outdoor Ready √

Vandal rating    IK10

IP rating    IP66, IP67

Designed for repaint √

Sustainability PVC free

Power

Power (max)    13.8 W

Power (average)    8.6 W
